JE, Acura, 3.386 in. Bore, Single

$220.05
SKU: BHXG-204256S

JE, Acura, K Series, 3.386 in. Bore, 9.00:1, Dome, Single Piston

JE Pistons is the leader in forged racing pistons. With 70-plus years of experience, in-house forging, and industry-leading technology, JE Pistons are designed to perform at the top levels of all forms of motorsports.

Additional Attributes:

GTIN: 00193564009937
Cylinder Head: K20
Engine: K Series
Forging Type: Round
Industry: Automotive
Make: ACURA
Oil Ring Thickness: 0.119
Out of Stock Message: Call for Availability
Piston Avg Wt: 307
Piston Head Type: Dome
Piston Material: 2618
Piston Pin Length: 2.250
Piston Pin Material: 5115
Piston Pin Outside Diameter: 0.866
Piston Pin Wall Thickness: 0.150
Piston Volume: 4.6
Product Market: Sport Compact
Prop 65 (C, R or CR): CR
Prop 65 Yes/No: Yes
Ringset Included: Yes
Second Compression Ring Thickness: 0.048
Top Compression Ring Thickness: 0.048
Add-On: JC2704-3386
Add-On: 866-2250-15-51C
Add-On: 866-063-MW
Bore Diameter: 86.00
Compression Height: 1.176

Extened Information:

Emissions : Electronically Announced
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
