JE, Toyota, 3.425 in. Bore, Single

JE Pistons is the leader in forged racing pistons. With 70-plus years of experience, in-house forging, and industry-leading technology, JE Pistons are designed to perform at the top levels of all forms of motorsports.

Additional Attributes:

GTIN: 00193564025265
Add-On: JG1001-3425
Add-On: 866-2250-15-51C
Add-On: 866-063-MW
Bore Diameter: 87.00
Compression Height: 1.181
Cylinder Head: 2JZ-GTE
Engine: 2JZ-GTE
Forging Type: FSR
Industry: Automotive
Make: TOYOTA
Oil Ring Thickness: 0.141
Out of Stock Message: Call for Availability
Piston Avg Wt: 296
Piston Head Type: Dish
Piston Material: 2618
Piston Pin Length: 2.250
Piston Pin Material: 5115
Piston Pin Outside Diameter: 0.866
Piston Pin Wall Thickness: 0.150
Piston Volume: -23.4
Product Market: Sport Compact
Prop 65 (C, R or CR): CR
Prop 65 Yes/No: Yes
Ringset Included: Yes
Second Compression Ring Thickness: 0.048
Top Compression Ring Thickness: 0.04

Extened Information:

Emissions : Electronically Announced
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
