SRP, Chevrolet, 4.560 in. Bore, Single

SKU: BHXG-152154S

SRP, Chevrolet, Big Block Chevrolet, 4.560 in. Bore, 1.395 CD, Dome, Single Piston

JE Pistons SRP line is proud to offer huge performance for the price. Forged from strong, 4032 aluminum alloy material, SRP pistons blend strength with affordability, offering an excellent performance bargain for performance rebuild and street/strip applications. (some applications in 2618)

Additional Attributes:

GTIN: 00193564262684
Add-On: S100S8-4560-5
Add-On: 990-2930-15-51S
Add-On: 990-042-CS
Bore Diameter: 4.560
Compression Height: 1.395
Cylinder Head: OPEN CHAMBER
Forging Type: FSR
Industry: Automotive
Oil Ring Thickness: 0.188
Out of Stock Message: Call for Availability
Piston Avg Wt: 672
Piston Head Type: Dome
Piston Material: 2618
Piston Pin Length: 2.930
Piston Pin Material: 5115
Piston Pin Outside Diameter: 0.990
Piston Pin Wall Thickness: 0.150
Piston Volume: 39
Product Market: Domestic
Prop 65 (C, R or CR): CR
Prop 65 Yes/No: Yes
Ringset Included: No
Second Compression Ring Thickness: 0.064
Top Compression Ring Thickness: 0.064

Extened Information:

Emissions : Electronically Announced
Life Cycle Status: Available To Order


Quantity of Each: 1
Package UOM: EA
