SRP Pro 2618, Chevrolet, 4.005 in. Bore, Single

SKU: BHXG-324858S

SRP Pro 2618, Chevrolet, Big Block Chevrolet, 4.005 in. Bore, 1.560 CD, Inverted Dome/Dish, Single Piston

JE Pistons SRP Pro 2618 line expands on the premium features of the SRP Pro series with the addition of extremely strong, 2618 forged aluminum material. All piston kits include gas-nitrided, carbon-steel pistons rings, pins, and locks. This line represents maximum piston strength at minimum cost.

Additional Attributes:

GTIN: 00193564254580
Prop 65 Yes/No: Yes
Ringset Included: No
Second Compression Ring Thickness: 0.06
Top Compression Ring Thickness: 0.048
Add-On: JG3108-4000-7
Add-On: 927-2250-15-51C
Add-On: 927-073-MW
Bore Diameter: 4.005
Compression Height: 1.560
Cylinder Head: STD CHEVROLET 23 DEG
Forging Type: FSR
Industry: Automotive
Oil Ring Thickness: 0.119
Out of Stock Message: Call for Availability
Piston Avg Wt: 469
Piston Head Type: Dish
Piston Material: 2618
Piston Pin Length: 2.250
Piston Pin Material: 5115
Piston Pin Outside Diameter: 0.927
Piston Pin Wall Thickness: 0.150
Piston Volume: -10
Product Market: Domestic
Prop 65 (C, R or CR): CR

Extened Information:

Emissions : Electronically Announced
Life Cycle Status: Available To Order


Quantity of Each: 1
Package UOM: EA
